Swit S 3812S

Chargeur rapide V-Mount 2 voies simultanées
S 3812S
Image(s) non contractuelle(s)

Offres en cours
Le S-3812 est un chargeur rapide 2 voies avec une intensité max de 6A. Il est équipé d'une sortie d'alimentation et d'un écran LCD vous indiquant l'état de charge de vos batteries.

Sur commande : Expédition sous 3 à 21 jours

498,00 € TTC

415,00 € HT
Vi code : S-3812S - Id : 925490

Dual-channel Fast Charger - Max charging current: 6A
S-3812S can charge 2 V-mount batteries simultaneously at Max 6A fast charging current, to SWIT particular batteries. The charging speed is quite faster than normal chargers. The following battery models support 6A fast charging:S-8340S, S-8360S, D-8161S And for other batteries, the charging current is 3A

Comparaison du temps de charge

Model de la batterie
S-8340S
S-8360S
D-8161S
S-8110S
S-8160S
S-8180S
Capacité
160Wh
250Wh
190Wh
130Wh
190Wh
220Wh
Temps de charge normal
6h 20m
9h 30m
7h 40m
4h 45m
7h 40m
8h 30h
Temsp de charge S-3812
2h 35m
3h 50m
2h 55m
3h 25m
5h 05m
5h 55m


AC-DC Adapting Output

S-3812S supports 1-ch AC-DC adapting output via 4-pin XLR port. By S-7102 (4-pin XLR female to male) cable, it can supply 16.8V DC power to the other equipments, Max load 200W/12A.When adapting load is less than 100W, S-3812S can still charge battery simultaneously. (2 batteriessequential)
Remark: S-7102 cable is optional purchased.

Battery-DC Adapting Output
You can also mount batteries onto S-3812S, and output DC power via 4-pin XLR port. By S-7102 (4-pin XLR female to male) cable, it can supply 16.8V DC power to the other equipments, Max load 200W/12A.
Remark: S-7102 cable is optional purchased.

LCD Charging Info Display
S-3812S has an LCD screen to display the real time charging/adapting information, includes:

Battery Charging/Discharging statusReal time capacity and percentageReal time Voltage/CurrentRemaining time to fully chargedRemaining time to fully dischargedBattery cycle timesAdapting output current and power
Remark: The battery info display only available with SWIT digital Li-ion batteries: S-8320S; S-8340S; S-8360S; D-8161S/R. For other non-digital batteries, the charger will only display real time voltage and current.

3-color LED Indicators
S-3812S has the 3-color LED indicators for both 2 channels:Red light slowly flashes: The battery is charging
Red light fast flashes: The battery is about to fully charged
Green light constant: The battery is fully charged
Green light flashes: The battery is adapting output
Orange light flashes: Battery or Charger abnormal alert

Input 100?240VA, 50/60Hz
Power consumption Max 260W
Charging output DC 16.8V, Max 6A×2-ch
Adapting output DC 16.8V, Max 12A
Working temperature 0°C?+40°C
Working humidity 10%?90%
Dimensions 272mm×246mm×97mm
Weight Approx. 1.85kg

Contenu de ce pack:
